Specifications
| Master data | |
|---|---|
| Manufacturer / Brand | SAJ |
| Storage type | High voltage |
| Subcategory name | Battery Module |
| Product warranty | 10 years |
| Technical data | |
|---|---|
| Net capacity | 9 kWh |
| Max. charging power | 4.6 kW |
| Protection class | IP66 |
| Battery storage features | Suitable for outdoor use |
| Number of full charge cycles | 10000 cycles |
| Max. discharge power | 4.6 kW |
| Maximum depth of discharge | 100 % |
| Max. discharge current | 11.8 A |
| Maximum altitude of the installation site (above sea level) | 3000 m |
| Max. charging current | 11.8 A |
| Nominal battery capacity | 9 kWh |
| Ambient temperature | -30 … +50 °C |
| Permissible relative humidity | 5 … 95 % |
| Type of input voltage | DC |
| Type of voltage | DC |
| Cooling method | Passive cooling |
| Logistics data | |
|---|---|
| Width | 270 mm |
| Height | 835 mm |
| Net weight | 79.2 kg |
| Depth | 270 mm |
Documents
Installation instructions
EK70_HS5-(8K-20K)-T3-X_Quick_Guide_V0_0_multilan_EU.pdf
English (US)
Manual
EK70_HS5-(8K-20K)-T3-X_User_Manual_V0_0_en_EU.pdf
English (US)
Data sheet
EK70 HS5 Dreiphasige All-in-One-Speicherlosung-DE.pdf
German / Deutsch
Declaration of Conformity
EU Declaration of Conformity--HS5.pdf
English (US)
Warranty
SAJ_EK70_HS5_Garantie_EU_Deutsch.pdf
German / Deutsch
Warranty
SAJ Limited Warranty for residential EK70 HS5 system (EU).pdf
English (US)
